ARC 200
Stick Welding
No items found.
Get in Touch. We'd Love to Hear From You.
The Blue Arc ARC 200 MMA welding inverter isequipped with the latest IGBT technology and a singularPCB for improved efficiency and maintenance. Thistechnologically advanced inverter is extremely user friendlyand offers reliable and consistent arc performance.The Arc200 also offers lift TIG functionality making it an ideal choicefor maintenance and light fabrication.
Get in Touch. We'd Love to Hear From You.
Optional
Key Features
- IGBT Inverter technology
- Stick, Arc-Force, Hot Start, Lift TIG
- 40KHZ inverter frequency high - efficiency
- Compact size, lightweight and modern design
- Easy arc starting, minimal spatter
- Auto-compensation for voltage fluctuation
- High quality tactile rubber finish to mouldings and handle
Technical Data
AC Power:
AC 230V - 50/60 Hz
Dimensions (L x W x H mm):
351 x 130 x 250
IP Class:
Class: IP21/F
Volt:
Range 10 - 200
Amperes (Amps):
Range 10 - 200
Effective Input Current (Ieff):
kVA (Input Power):
12.3
Weight:
5.2 kg
No-Load V:
63
Duty Cycle:
250A @60%
Power Factor:
0.7
Efficiency (%):
85
Fuse:
Wire Spool:
Wire Feed Speed:
CUT (Cutting Capacity):
Air Cimpressor/Gas Flow:
Technical Data Header:
Package Includes:
Inverter power source, Operating instructions
Not Included:
(Available from your local suppliers)
Main plug, Electrodes, Cable set, PPE (Weldinghelmet, gloves, etc)
